| Place of Origin: | CHINA |
|---|---|
| Brand Name: | TENGDA |
| Certification: | CE,ISO |
| Model Number: | GPW-350C |
| Minimum Order Quantity: | 1 set |
| Price: | ¥130000-200000/ set |
| Packaging Details: | wooden cases |
| Delivery Time: | 30 work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 50 set per month |
| Material: | Stainless Steel | Color: | Silver |
|---|---|---|---|
| Speed: | 100-150 Bags/min | Machine Weight: | About 1160Kg |
| Machine Size: | (L)4200×(W)960×(H)1520mm | Film Width: | 80-350mm |
| High Light: | pharmaceutical packaging machines,medicine packaging machine |
||
Perfect service system Medical Packing Machine with high quality services
The main performance and structure characteristics
1, three servo control, bag length is set is cut, don't need to adjust empty, one pace reachs the designated position, convenient province membrane.
2, no empty bag function.Automatically in downtime, the film cutter to stop, pushing automatically.No empty package, do not waste envelope without artificial feeding.
3, built-in temperature control module, temperature independent PID control, temperature control precision, better suited to a variety of packaging materials.
4. Frequency control with fast dynamic follow-up performance and high speed accuracy, automatically correct the frequency, in order to achieve the load changes when the motor speed stability. The length of the bag that is set to cut, no need to adjust the empty walk. When a fault occurs, the device alarms and the display shows the corresponding message and the device stops operating.
5. Electrical system intact, electrical components installed fastening, reliable wire connection, electrical components without damage
Scope of application:
It is specially designed for the packaging of the aluminum foam cover plate and other similar materials.
|
The machine type
|
GPW-350 |
|
Film Width
|
Max.350mm |
|
Bag length
|
100~200mm |
|
Product Height
|
10~50mm |
|
film diameter
|
Max.400mm |
|
Packing speed
|
5~150package/minute
|
|
power
|
220V50/60Hz3.2Kw |
|
Machine size
|
(L)4200×(W)960×(H)1520mm |
|
machine weight
|
About 1160Kg |
|
Air Pressure
|
≥0.2 MPa |
