| Place of Origin: | china |
|---|---|
| Brand Name: | tengda |
| Certification: | CE， ISO9000 |
| Model Number: | PW-300E |
| Minimum Order Quantity: | 1set |
| Price: | ¥40000-60000/set |
| Packaging Details: | wooden cases |
| Delivery Time: | 20days |
| Payment Terms: | L/C, T/T, MoneyGram |
| Supply Ability: | 50 sets per month |
| Weight: | 450kg | Color: | Silver |
|---|---|---|---|
| Packing Material: | Composite Membrane | Encasement: | Wooden Case |
| Material: | Stainless Steel | Advantage: | High Speed |
| High Light: | horizontal form fill seal machine,flow wrap machine |
||
Automatic blanking flow pouch packing machine has One year repair for free
and maintenance for lifetime
The main performance and structure features:
1. Fault self-diagnosis function, fault shows at a glance.positioning stop function, non-stick knives, at no cost.
2. All the controlling operates by the software, convenience for function adjustment and technical up grading.
3. with high-end appliances, touch human-machine interface, convenient
parameter setting.
4. Clean rotation system, more reliable operation and more convenient maintenance.
5. the rotation system is simple, more reliable, more convenient maintenance.
6. packaging machine: packaging machine for packaging when the force is generally small, so the motor function is small, generally less than 1KW; packaging machine generally adopts stepless speed change device, so as to adjust the packing speed, adjusting packing machine production capacity; can improve the production efficiency, but also ensure the quality of product packaging.
7. Application of pillow type packing machine in the food industry and the pharmaceutical packaging industry, greatly improving the health level of the packaging process, to achieve full closure, no chisel, clean packaging packaging process, packaging industry development is a milepost, also lifted people tedious work, make the efficiency of packing is greatly improved, for the packaging industry the rapid leapfrog development provides a new platform.
scope of application:
Applicable to regular shaped objects Special packing for food like Dried mango.
.
Technical parameter:
|
Finished package size (mm) |
Length | 40-500mm |
| Width | 30-110mm | |
| Height | 5-40mm | |
| Vertical and cross sealing strength (Nuton/mm2) | ＞15N/m㎡ | |
| Packaging speed bag/minute | 5-230Bags/min | |
| Packaging film width(mm) | 80-300mm | |
| Power specification | 220V50/60Hz2.4KVA | |
| Machine weight (kilogram) | 400kg | |
| Overall size (lengthXwidthXheight) | 3780×640×1560mm | |
Description: as mentioned above,
1. packaging products before packaging materials into the packaging material,
2. package material has been molded by the shaper,
3. package material will immediately wrap the product with the product,
4. the supply wheel and the middle sealing wheel begin to heat seal, and the middle seal is finished,
5. the product reaches the end seal and cuts off the seal.
