| Place of Origin: | china |
|---|---|
| Brand Name: | tengda |
| Certification: | CE |
| Model Number: | PW-300C |
| Minimum Order Quantity: | 1set |
| Price: | Negotiable |
| Packaging Details: | woods |
| Delivery Time: | 30days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 50set/month |
| Material: | 304 Stainless Steel | Machine Model: | PW-300E |
|---|---|---|---|
| Delivery: | Twenty Days | Encasement: | Wooden Case |
| Color: | Milky White/silver | Power Specification: | 220V 50/60HZ 2.4kw |
| High Light: | capsule blister packaging machine,tablet blister packaging machine |
||
stainless steel Blister Packing Machine has One year repair for free and maintenance for lifetime
Equipment capability:
1. for the traction roller and the vertical roller, their movement first maintains the material to have the suitable tensioning in the entire movement process; secondly, their movement speed should adapt with the bag appearance.
2. setting and control of sealing and cutting temperature.can realize color mark tracking trademark to its function.the whole operation is stable and reliable, and can adapt to various specifications of the adjustment. mature technology, stable quality, faster and more stable packaging, low energy consumption, low manual, low reject rate.can be used in the packaging of non trademark packaging materials, and can use the pre printed trademark reel material for high-speed packaging.
3. All sensors try to use the plug, socket connection, easy assembly and disassembly.
4. quipment operation should be smooth, moving parts movements should be sensitive, coordinated, accurate, no card twisting and abnormal sound.
5. Stable operation, in normal work, the noise should not be greater than 82dB (A), no dust.
6. The machine should work properly when the deviation of the supply voltage from the rated voltage does not exceed -10% and + 5%.
technical parameters:
| Finished package size(mm) | Length | 40-500mm |
| Width | 30-110mm | |
| Height | 5-40mm | |
| Vertical and cross sealing strength (Nuton/mm2) | 15N／m㎡ | |
| Packaging speed (bag/minute) | 30-160Bags／min | |
| Packaging film width(mm) | 80-450mm | |
| Power specification | 220V 50／60Hz 3KVA | |
| Machine weight (kilogram) | 800kg | |
| Overall size (length * width * height) | 3780×640×1560mm | |
Automatic packaging machine with automatic measurement, filling, bagging, sealing, cutting off, conveying, printing production batch number, increase the easy incision, no material warning, mixing and other functions.
Description:
as mentioned above,
1. packaging products before packaging materials into the packaging material,
2. package material has been molded by the shaper,
3. package material will immediately wrap the product with the product,
4. the supply wheel and the middle sealing wheel begin to heat seal, and the middle seal is finished,
5. the product reaches the end seal and cuts off the seal.
